1、 Circular roller guide system of linear guide railht -圆滚子导向系统是一种具有无限行程和直线运动的支撑系统。具有精度高、承载能力大、刚度高、摩擦阻力小、稳定等特点。ht -圆形滚子导向系统适用于一般机械工程的许多应用，特别适用于对导向精度和定位精度要求较高、位移距离较长的机床直线导向系统。ht-循环滚子导向系统更重要的部件是ht-线性滚子轴承，其配合ht-hydrel导向作为滚道。ht调节楔提供精确的和可重复的对准制导系统。

　　HT - roller guide system is a support system with infinite stroke and linear motion. It has the characteristics of high precision, large bearing capacity, high rigidity, small friction resistance and stability. HT - circular roller guiding system is suitable for many applications of general mechanical engineering, especially for the straight-line guiding system of machine tools with high requirements for guiding and positioning accuracy and long displacement distance. The most important part of the HT cycle roller guide system is the HT linear roller bearing, which is used as the raceway with the HT hydrel guide. HT adjusting wedge provides precise and repeatable alignment guidance system.

　　二、直线导轨的平直式保持架导引系统

　　2、 Guide system of straight cage with straight guide railht直笼导向系统包括各种类型的导轨和带多滚轮的直笼组件。由于精密导轨之间的滚子数量较多，该制导系统的承载能力和刚度在所有ht-linear运动滚动制导系统中，占用空间更少。ht-straight cage制导系统摩擦小，精度高，在长时间的运行中精度保持稳定。滚子和直形保持架组件是为旅行受限而不是两个滚道运动的场合设计的。它可以用于一般机械的许多直线运动支架，特别是在机床安装中。

　　HT straight cage guide system includes various types of guide rails and straight cage components with multiple rollers. Due to the large number of rollers between the precision guide rails, the bearing capacity and stiffness of the guidance system are the highest among all the HT linear motion rolling guidance systems, and the occupied space is the least. The high precision and small friction of the HT straight cage guidance system keep stable in the long run. The roller and straight cage assemblies are designed for limited travel rather than two raceway movements. It can be used in many linear motion supports of general machinery, especially in the installation of machine tools.

　　三、直线导轨 循环式球轴承和导轨组件LKE

　　3、 Linear guide circulating ball bearing and guide assembly lkeht -圆形滚珠轴承和导轨总成LKE系列是特别高精密滚动轴承。它们可以调整为没有间隙。具有极低的摩擦阻力和无滞后现象。在空间利用的情况下，它们具有的承载力和刚度。再循环球轴承和导轨组件可以承受任何地方的横向载荷和任何方向的倾斜力矩，而不需要其他平衡装置。

　　HT - round ball bearing and guide rail assembly lke series are special high precision rolling bearings. They can be adjusted to have no gaps. It has very low friction resistance and no hysteresis. In the case of optimal space utilization, they have the best bearing capacity and stiffness. The recirculating ball bearing and guide rail assembly can bear transverse load and tilt moment in any direction without other balancing devices.

　　四、直线导轨的各种轮轴和心轴

　　4、 Various axles and spindles of linear guide railHt-linear滚珠轴承KH系列(冲压外圈圆形直线滚珠轴承)是由冲压硬化的外圈和一组滚球的塑料导架组成的完整的总成，可直接压入阀座孔内。总成与滑动轴承占用相同的空间。在外圈上有凹槽，使球能回到负荷区。

　　HT linear ball bearing KH series is a complete assembly composed of a stamping hardened outer ring and a group of plastic guide frames for rolling balls, which can be directly pressed into the valve seat hole. The assembly and the sliding bearing occupy the same space. A groove is arranged on the outer ring to enable the ball to return to the load area.

　　ht型直线滚珠轴承只能用于直线运动轴导轨。不能用作旋转运动部件的支撑。由于其不受限制的行程、低的空间要求以及低的维护和设计成本，它被广泛应用于通用机械中。

　　HT type linear ball bearing can only be used for linear motion axis guide rail. Cannot be used as a support for rotating moving parts. Because of its unlimited travel, low space requirements and low maintenance and design costs, it is widely used in general machinery.
